1.Product Introduction

AVR-D series single phase microcomputer full automatic AC voltage stabilizer is a new generation of intelligent voltage stabilizing equipment which has been successfully developed after years of research and production.

 It adopts the latest single-chip operation and measurement chip control technology, fast AC sampling technology, effectively value correction technology and rapid compensation and voltage stabilization technology. It combines intelligent meters, rapid voltage regulation and fault diagnosis to make safe, efficient and precise product.

It is mainly composed of an isolation transformer, an auto-regulator, a CPU control core, intelligent voltage stabilization technology, and safety protection device. This  intelligent voltage stabilizer realizes a fully automatic control, safe, efficient, energy-saving, and environmentally-friendly.

2.Working Environment

AVR-D series voltage stabilizer should be used indoors. For outdoor use, customization is available, please contact our salesperson.

Ambient temperature: -15°C~+40°C

Relative humidity; ≤90%

Altitude: ≤1000m

No vibration or bumps in the installation site

There is no gas, steam, chemically deposited dust, dirt and other explosive and corrosive media that seriously affect the voltage and insulation.

·Power Factor is 1

KVA is equal to KW.

·Automatic Voltage Regulation

Digitally controlled voltage stabilization

·Choice of Input Voltage Swing Ranges

Input Range - ±15%, ±20%, ±25%, ±30% (Can be customized)

·Precise Output Voltage Regulation

Output Voltage Accuracy ±1% to ±5%

·Multi-protection Design

Highly reliable and endurable design.   With the protection of over-voltage, under-voltage ,over-load, short-circuit, manual bypass.

·Preset Function:

Support users to change the protection value settings according to the actual situation.

·Manual Bypass Function,

Easy to maintain the voltage stabilizer.  Support users to switch between "AVR" and "Bypass , which is convenient for fault maintenance.

This product is widely used for household appliance,  office equipment, testing equipment, medical equipment, industrial automation equipment, lighting system, communication system, etc.
